Metal Gland:Cable OD 5-9mm

Product Description

The GU range of unarmoured metric cable glands are perfect for use with PVC, XLPE and other synthetic cables.

These glands are rated IP68, with a nickel plated brass body to guard against the effects of corrosion and a fully insulated seal to ensure fluid tightness.

Unlike many traditional glands, the GU range has a camera shutter style sealing mechanism which allows each gland to fit a wide cable diameter range without sacrificing ingress protection.

How to Install:
Installation is extremely simple, just pass the cable through the assembled gland and tighten gland nut until the cable is secured. The gland has strain relief and twisting protection rated to DIN VDE 0619, so you can be sure that you are working with a quality product.

Locknut sold separately.

Dimensions

Mounting Dia. (A): 16mm
Thread Length (B): 10mm
Min. Cable Range: 5mm
Max. Cable Range: 9mm
Width (A/F): 17mm
Recommended Torque: 6Nm
Locknut: LNM16

To browse other sizes of unarmoured metal cable glands, view the product range or refer to the product data sheet for a size selection guide.

Technical Data

Conformant Standard: DIN 46 319 (brass glands metric)
IP Rating: IP68
Threading: According to IEC 423, IEC 423A and EN 60423
Chemical Resistance: Resistant to normal organic solvents, mineral, animal and vegetable oils, fat and petrol
Continuous Operating Temperature: -20 to +100 degrees Celsius
Strain Relief and Twisting Protection: To DIN VDE 0619

Nickel plated brass body
Polyamide 6 insert (self-extinguishing)
Neoprene seal (self-extinguishing)
Neoprene O-ring (self-extinguishing)
